3 In 1 Stator Testing Machine, Hipot, Surge And Winding Resistance Test
1. Product introduction
3 in 1 stator testing machine can be used to test the stator of both single-phase and three-phase motor. The electrical parameters of the stator on EV, fan, air conditioner, power tools etc. can be tested accurately.
2. Test items: surge, winding resistance, AC Hipot
3. Main features:
Hipot, insulation resistance, surge and winding resistance can be tested at one-stop in case the wire has been connected well.
The testing machine is featured with easy maintenance, high accuracy, test fast, easy-to-operate, high compatibility, intelligent design, modular design, multiple interfaces.
4. Technical parameters
| Test item | Surge, winding resistance, Hipot, | ||
| Test object | Stator | ||
| Test station | Desk type, no test bench | ||
| Surge | |||
| output voltage setting range/precision | 500～3000V ±(3%×display value+8V) | ||
| waveform comparison | area, area difference, corona, phase three waveforms will be displayed on the testing interface | ||
| Winding resistance | |||
| measuring range and precision | 5mΩ～2KΩ ±(0.5%×readinge+2 words) temperature compensation can be set | ||
| test time range/resolution | 1～300s 1s/step | ||
| Hipot | |||
| output voltage setting range/precision | AC 200～3000V ±(1.5%×setting value+10V) | ||
| breakdown current presetting alarm range | Max: 0.10～20.00mA; Min: 0.00～20.00mA | ||
| test time range/resolution | 0.5～999.9s 0.1s/step | ||
